NECS ENGINEERS

SOLAR SYSTEM

Package option

Class 3B – 16kW Deye single phase Solar System

Estimated duration: 4 days

R 203 892,87R 207 085,87

Products included

Equipment supplied with this option

Deye hybrid inverter 16kw(single phase)
Deye hybrid inverter 16kw(single phase)× 1
Solar panel 605-640W JA mono - bifacial
Solar panel 605-640W JA mono - bifacial × 18
Battery Lithium VOLTA STAGE 1 - 5.12Kwh Wallmount and floorstand(NEW Generation)
Battery Lithium VOLTA STAGE 1 - 5.12Kwh Wallmount and floorstand(NEW Generation)× 4
AC Combiner box 16kw Inverter Single phase
AC Combiner box 16kw Inverter Single phase× 1
DC Combiner Box 2 in 2 out 5kw/6kw/8kw/12kw/15kw/16kw/18kw Inverters
DC Combiner Box 2 in 2 out 5kw/6kw/8kw/12kw/15kw/16kw/18kw Inverters× 2
Automatic change over 2Pole-Dual power transfer switch Q-KG630
Automatic change over 2Pole-Dual power transfer switch Q-KG630× 1
Roof tile mounting bracket galvanized
Roof tile mounting bracket galvanized× 42
Mounting Rail 3.5m eco galvanised
Mounting Rail 3.5m eco galvanised× 14
Galvanized ECO Mounting end clamp
Galvanized ECO Mounting end clamp× 12
Galvanized ECO Mounting mid clamp
Galvanized ECO Mounting mid clamp× 34
Solar Cable 6mm (BLACK)-per meter
Solar Cable 6mm (BLACK)-per meter× 50
Solar Cable 6mm (RED)-per meter
Solar Cable 6mm (RED)-per meter× 50
Earth / ground 6mm² Cable per m
Earth / ground 6mm² Cable per m× 30
MC4 Connectors(male&female)
MC4 Connectors(male&female)× 6
Battery fuse holder 250amp
Battery fuse holder 250amp× 1
Fuse Blade 48V NH1 250A VOLTA
Fuse Blade 48V NH1 250A VOLTA× 2
Battery Cable 35mm Black
Battery Cable 35mm Black× 8
Battery Cable 35mm Red
Battery Cable 35mm Red× 8
Battery Cable 70mm Black
Battery Cable 70mm Black× 4
Battery Cable 70mm Red
Battery Cable 70mm Red× 4
Battery Busbar box
Battery Busbar box× 1
Lugs 35mmx10
Lugs 35mmx10× 22
Lugs 70mmx10
Lugs 70mmx10× 8
TEK Screws with bonded washer per pack(50) 3A40
TEK Screws with bonded washer per pack(50) 3A40× 1
AC 10mm² Red Cable
AC 10mm² Red Cable× 30
AC 10mm² Black Cable
AC 10mm² Black Cable× 30
Trunking 100x40
Trunking 100x40× 6
Trunking End Cap
Trunking End Cap× 1
Raw bolt M10 (16mm bit)
Raw bolt M10 (16mm bit)× 16
PVC Female 20mm
PVC Female 20mm× 30
fisher plugs/ Nail in Anchors 10mm
fisher plugs/ Nail in Anchors 10mm× 60
Earth spike (1,2m
Earth spike (1,2m× 2
PVC flexible conduit(per meter)
PVC flexible conduit(per meter)× 10
TEK Screws with bonded washer per pack(50) 3A15
TEK Screws with bonded washer per pack(50) 3A15× 1
Pvc 20mm clip
Pvc 20mm clip× 36
PVC Conduit Pipe 25mm
PVC Conduit Pipe 25mm× 9
coupling 20mm PVC
coupling 20mm PVC × 27
Silicone Sealant
Silicone Sealant× 1
