NECS ENGINEERS

SOLAR SYSTEM

Package option

Class 4A – 30kW Deye LV 3Phase Solar System

Estimated duration: 5 days

R 591 468,30R 599 534,30

Products included

Equipment supplied with this option

DEYE 15KW LV Three Phase Hybrid inverter
DEYE 15KW LV Three Phase Hybrid inverter× 2
Solar panel 605-640W JA mono - bifacial
Solar panel 605-640W JA mono - bifacial × 72
Battery Lithium VOLTA STAGE 4 - 14.34 Kwh Wallmount and floorstand(NEW Generation)
Battery Lithium VOLTA STAGE 4 - 14.34 Kwh Wallmount and floorstand(NEW Generation)× 4
AC Combiner box 15kw Inverter for 3Phase Inverters
AC Combiner box 15kw Inverter for 3Phase Inverters× 2
DC Combiner Box 2 in 2 out 5kw/6kw/8kw/12kw/15kw/16kw/18kw Inverters
DC Combiner Box 2 in 2 out 5kw/6kw/8kw/12kw/15kw/16kw/18kw Inverters× 2
DB 12 Way VOLTA Wall mount
DB 12 Way VOLTA Wall mount× 1
Automatic Transfer Switch (ATS) 250A - 3Phase, 4 Pole in Enclosure
Automatic Transfer Switch (ATS) 250A - 3Phase, 4 Pole in Enclosure× 1
Mounting Rail 3.5m eco galvanised
Mounting Rail 3.5m eco galvanised× 54
Roof tile mounting bracket galvanized
Roof tile mounting bracket galvanized× 170
Galvanized ECO Mounting end clamp
Galvanized ECO Mounting end clamp× 56
Galvanized ECO Mounting mid clamp
Galvanized ECO Mounting mid clamp× 142
Solar Cable 6mm (BLACK)-100m roll
Solar Cable 6mm (BLACK)-100m roll× 12
Solar Cable 6mm (RED)-100m roll
Solar Cable 6mm (RED)-100m roll× 12
6mm GP Cable (Copper) earth per meter
6mm GP Cable (Copper) earth per meter× 200
MC4 Connectors(male&female)
MC4 Connectors(male&female)× 36
Battery Busbar box
Battery Busbar box× 1
Battery fuse holder 250amp
Battery fuse holder 250amp× 2
Fuse Blade 48V NH1 250A VOLTA
Fuse Blade 48V NH1 250A VOLTA× 6
Battery Cable 70mm Black
Battery Cable 70mm Black× 4
Battery Cable 70mm Red
Battery Cable 70mm Red× 4
Battery Cable 35mm Black
Battery Cable 35mm Black× 8
Battery Cable 35mm Red
Battery Cable 35mm Red× 8
Lugs 70mmx10
Lugs 70mmx10× 16
Lugs 35mmx10
Lugs 35mmx10× 24
TEK Screws with bonded washer per pack(50) 3A40
TEK Screws with bonded washer per pack(50) 3A40× 4
AC 10mm² Black Cable
AC 10mm² Black Cable× 10
AC 10mm² Red Cable
AC 10mm² Red Cable× 20
AC 10mm² Blue Cable
AC 10mm² Blue Cable× 20
AC 10mm² Yellow Cable
AC 10mm² Yellow Cable× 20
AC 16mm² Black Cable
AC 16mm² Black Cable× 40
AC 16mm² Red Cable
AC 16mm² Red Cable × 40
AC 16mm² Blue Cable
AC 16mm² Blue Cable × 40
AC 16mm² Yellow Cable
AC 16mm² Yellow Cable× 40
Trunking 100x40
Trunking 100x40× 10
Trunking End Cap
Trunking End Cap× 20
Raw bolt M10 (16mm bit)
Raw bolt M10 (16mm bit)× 8
PVC Female 20mm
PVC Female 20mm× 40
fisher plugs/ Nail in Anchors 6mm
fisher plugs/ Nail in Anchors 6mm× 100
Earth spike (1,2m
Earth spike (1,2m× 5
PVC flexible conduit(per meter)
PVC flexible conduit(per meter)× 25
PVC Conduit Pipe 25mm
PVC Conduit Pipe 25mm× 12
Pvc 20mm clip
Pvc 20mm clip× 48
coupling 20mm PVC
coupling 20mm PVC × 36
Silicone Sealant
Silicone Sealant× 4
